Plain Tiles Plank

Description

Explore endless design possibilities by mixing and matching Zintra Etch and Plain Tiles. With a diverse range of shapes and a vibrant colour palette, you have the freedom to select from a spectrum of hues, bringing your design vision to life and creating an acoustically minded space.

Experience effortless installation with our lightweight and seamless Zintra tiles, ensuring a smooth and hassle-free process. Whether installed wall to wall or as captivating feature artwork, they're the perfect fit for any commercial, educational, or hospitality setting, seamlessly merging aesthetics with acoustic excellence.

Plank*

Inspired by the beauty of natural wood, Plank brings a touch of warmth and organic elegance to your space. This captivating pattern showcases a series of interlocking planks, creating a visually stunning and versatile design.

Available in 14 designs (Includes Tablet – available in 3 sizes):

• Battleaxe*
• Chevon*
• Diamond*
• Herringbone*
• Hexagon*
• Hourglass*
• Jigsaw
• Parallelogram
• Plank*
• Rectangle
• Square*
• Tablet

* Notes: Designs available in both Plain and Etch.

Tiles are sold in sets.

Not suitable as a free-standing product.

Dimensions

Plank:

• 26 Tiles / set, 3.1m² (33.5 SF)
• 600mm (23.62") h x 200mm (7.87") w

Composition

Zintra Acoustic Panel - 100% Solution Dyed (Colour Through) Polyester

• 12mm (1/2") - Density 2.4 kg /m² (0.5 lb/ft²)

Sustainability

• Zintra is made from 100% recyclable materials.
• 60% post-consumer recycled content from PET bottles.
• 35% pre-consumer recycled content from PET chips.
• 5% polylactic acid (PLA).

Fire Rating

• ASTM-E84 – Class A classification
• AS ISO 9705 – 2003 – Group 1 classification
• EN-13501 – B-s2-d0 classification

Assembly & Delivery

• Ships Flat Packed.
• Supplied as a set of individual tiles.
• Arrange as required.
• Go to the Technical Documents and download the Installation Guide for more details.

Supplied As

• Plank: 26 tiles / set, 3.1m² (33.5 SF)

Suggested Installation

Go to Technical Documents and download the Installation Guide for more details.

How to Specify

• Select Design
• Select Zintra Colour

Care Instructions

• Vacuum to remove dust.
• Dab Zintra with a damp clean cloth and mild solution of liquid detergent and warm water. Repeat using only clean water, then pat dry with a lint-free cloth.
• For difficult stains, use a solution of household bleach (10% bleach / 90% water). To remove the bleach, repeat using a clean, water-dampened cloth, then pat dry.
• Always test in an inconspicuous area first, and if you don't see the expected results, contact us.

Customisable

The Zintra Acoustic Solutions range is customisable to your project. Please get in touch with your local contact for details.

Additional Comments

• NRC 0.45-0.75
• Directly Mounted
